During the energy crisis of the 1970s, a prevailing belief took root where it was thought that tightly sealing walls and ceilings with a vapor barrier was essential to blocking heat transference and reducing energy costs. It was soon determined, however, that unless the seal was absolute, moisture that did get into sealed walls could create serious structural problems and health issues, such as allergic reactions to mold festering within walls. Although it is still good practice to minimize heat loss through walls, ceilings, and floors, it is now known that it is equally important for the vapor barriers to be installed correctly and that walls also are able to "breathe."

Resolution of the Vapor Barrier Debate

Some debate still occurs over how necessary vapor barriers are, but a consensus is growing closer. Most authorities now agree that vapor barriers are important under certain conditions, but not necessarily as a whole-house solution for every home. In circumstances where conditions inside a home or office are much different than outdoor conditions, water vapor is likely to move through wall cavities and can get trapped inside, and a well-installed vapor barrier is recommended. Vapor barriers can also be important for certain rooms where moisture levels are especially high.

The Science of Moisture Movement

Water vapor can pass through building materials in several ways, including direct transmission, and by heat transfer, but studies suggest that fully 98 percent of the moisture transfer through walls occurs through air gaps, including cracks around electrical fixtures and outlets, and gaps along baseboards. Thus, installing vapor barriers on wall surfaces must be done in conjunction with sealing these air flow-gaps in walls and ceilings, and along floor surfaces. Note that a poor effort at establishing a vapor barrier may be worse than no effort at all. The goal of vapor barrier strategies is to prevent moisture from collecting and corrupting building materials. Improperly installed, a vapor barrier may actually trap moisture inside a wall, while a wall that is more porous can breathe effectively and be less susceptible to long-term moisture problems. This condition is especially problematic where vapor barriers are installed on inside as well as outside wall surfaces, as such a wall cannot breathe at all

Do I Need a Vapor Barrier?

Once thought to be essential throughout a home or office, vapor barriers are now strongly recommended only for certain conditions, and methods for creating a vapor barrier must be tailored to fit the climate, region, and type of wall construction. For example, the recommended vapor barrier in a home or office in a humid southern climate built with brick varies greatly from creating a vapor barrier in a cold climate in a home built with wood siding. Always refer to current local code recommendations when deciding if and how to install vapor barriers. Avoid adding interior vapor barriers where the outer wall construction already includes a material with vapor barrier properties.

Most authorities recommend vapor barriers in certain situations:

What is a shower wheelchair?

A shower wheelchair is a device made exclusively to help individuals with low mobility better navigate the bathroom, specifically the toilet and...

Last updated Oct 30, 2021

How deep should a shed footer be?

Large shed footings should extend 12” below the frost line (meaning a depth of 24”, 36”, 48”, or more depending on the local climate). Dec 17, 2021

Last updated Aug 20, 2022

These are the Best Shed Plans!

Comprehensive and Intuitive to follow. Build That Shed!

Learn More »

Promotion

In areas with high humidity—such as greenhouses, rooms with spas or swimming pools, and bathrooms—vapor barriers are often recommended. Consult building inspection offices for local recommendations. In very cold climates, the use of polyethylene plastic vapor barriers between insulation and interior wallboard may be beneficial, provided all air gaps into any wall and ceiling cavities are also blocked. The exterior face of the wall or floor cavity should remain permeable in order to allow dissipation of any moisture that does enter the wall cavity. Very hot and humid climates may benefit from an exterior vapor barrier that keeps outside humidity from penetrating into walls. Below-grade walls and floor slabs transmit ground moisture through concrete walls or slabs. A vapor barrier against the concrete surface is generally recommended before wood framing or flooring materials are installed. Crawl spaces benefit from a polyethylene moisture barrier placed directly over the exposed earth.

Tips for Installing Vapor Barriers

If vapor barriers are warranted by local building practices and code recommendations, keep the following practices in mind: Buildings should meet ASHRAE standards 62.2 or 62.1 for proper ventilation before being sealed by complete vapor barriers. Modern homes or offices that are tightly sealed in order to be highly energy efficient should also have air-to-air heat exchangers or other methods of ensuring a good exchange of fresh air Don't use impermeable vapor barriers where semi-permeable or permeable materials provide satisfactory performance. Construction methods that allow interior wall materials to dry out are considered better than those that seek to prevent all moisture from entering Vapor barriers are usually best installed on the side of the wall that experiences the hotter temperature and moister conditions: the inner surface in colder climates and the outer surface in hot, humid climates. In existing spaces, oil-based paints or vapor-barrier latex paints offer an effective moisture barrier. Avoid fully impermeable barriers, such as polyethylene or vinyl wall coverings, on spaces that are air-conditioned. This practice has been linked to moldy buildings and other air quality problems. Avoid installing vapor barriers on both sides of a structure. Walls and ceiling cavities should ideally have the ability to dry out in one direction if the other side is constructed to prevent moisture penetration. Seal all wall cracks and holes in the wall being vapor-proofed to block air gaps. Use special sealing tape to join sheets if polyethylene sheets are being used. Complete air blockage is essential to provide a satisfactory moisture barrier, and will also maximize the wall's energy efficiency.

Which uPVC door is best?

Top 5 uPVC Doors Profiles Liniar uPVC Doors. Liniar is a well known brand that has years of experience producing the highest quality uPVC, and of...

Last updated Jun 22, 2018

Will tools rust in a shed?

Hand Tool Storage To prevent this from happening, make it a habit to bring your hand tools in from the garage or shed at least an hour before you...

Last updated Jul 17, 2021

Can I build my own shed?

Yes, with the right plans you can build your dream shed.

Learn More »

Promotion

Use acoustic spray-foam sealant or sealant tape to block spaces around electrical boxes at outlets, switches, or ceiling light fixtures.

Vapor Transmission Ratings

To assist builders in controlling moisture, various building materials are rated according to permeability and are assigned a perms rating. A variety of rating systems are in use, but one common one is the U.S. permeability system. Impermeable materials are those rated at less than 1 U.S. perms. Some examples include:

Glass

Sheet metal

Polyethylene sheet

Rubber membrane

Vapor-retardant paints

Exterior-grade plywood

Foil-faced rigid insulation board

Semi-permeable materials are rated at 1 to 10 U.S. perms. Some examples include:

Unfaced expanded or extruded polystyrene

30-pound asphalt-coated paper (tar paper)

Interior-grade plywood

Bitumen-coated kraft paper

Foil- or paper-faced batt insulation

Gypsum board painted with oil-based or moisture-retardant latex paint

Permeable materials are rated at 10 U.S. perms or above. Some examples include:

Unpainted gypsum board (drywall)

Fiberglass insulation (unfaced)

Cellulose insulation

Board lumber

Concrete block

Concrete slabs

Brick

15-pound asphalt-coated paper (tar paper)

House wrap

Impermeable materials are not always desirable, as in some situations a wall needs permeable materials in order to properly breathe and rid itself of excess moisture. Most experts advise against sealing a wall on both sides, as this is a prescription for trapping moisture and fostering the inherent problems it creates.
