Can you lay slabs without a sub-base?

Do I really need a Sub-base? The short answer is: if the pavement will be trafficked by vehicles, then yes, but if it will be foot-traffic only, then not necessarily. The type of paving or surfacing that will be used is one of the key factors in determining whether a sub-base will be required.

pavingexpert.com - FAQ for Sub-bases | Pavingexpert

How do truck drivers not get fat?

It's essential for drivers' health and safety to avoid obesity and keep their weight in check. Short periods of regular exercise, eating fresh...

Last updated Jul 3, 2021

How much does it cost to get electricity in a shed?

The biggest determiner of the final price is whether you will be doing the work or hiring a licensed electrician. If you plan on hiring an...

Last updated Aug 1, 2020

Promotion

Do I really need a Sub-base?

The short answer is: if the pavement will be trafficked by vehicles, then yes, but if it will be foot-traffic only, then not necessarily. The type of paving or surfacing that will be used is one of the key factors in determining whether a sub-base will be required. Some paving types, block paving for example, nearly always need a sub-base, while others, such as pattern imprinted concrete, may not need one, but wouldn't be any less effective if one was to be included. See Table 1 below for a summary. Bear in mind the comments made on the Introduction to Sub-bases regarding their role within a paved area, how they help spread loads and provide an 'underlay' to the 'carpet' of paving. You should only exclude a sub-base if there is good reason to do so. Compacting a sub-base using a Plate Compactor

Type of paving Sub-base? Thickness (mm) Comments

Flexible Block Paving Always 75-150 75mm min for foot traffic only,100-150mm for driveways,150mm+ for commercial applications

Rigid Block Paving Usually 100-225 May be used beneath base

Patio Flags Occasionally 75-100 Not necessary, but useful if levels need to be elevated Indian Sandstones Occasionally 75-100 Not necessary, but useful if levels need to be elevated Yorkstone flags Occasionally 75-150 Not necessary for foot traffic, but may be used when constructing a driveway BS Flags Usually 75-150 Not necessary for patios, but may be used when constructing a driveway, and often specified for commercial works Gravel Usually 75-150 May be omitted in decorative areas, but must be used for trafficked areas

Setts/Cubes Usually 75-150 Optional for rigid construction; essential for flexible construction

Cobbles Occasionally 75-150 May be used beneath a base layer

Tarmac Always 100-150 100mm for footways and light driveways

Concrete - PIC Usually 100-150 Often omitted beneath PIC on driveways, which is not always a good idea

Resin Systems Usually 75-150 Depends on substrate type

Table 1: Requirements for Sub-base and recommended thicknesses

How deep should my sub-base be?

Generally, a flexible sub-base of unbound material needs to be at least 100mm deep, as does a bound sub-base of CBM/HBM. For bitumen-bound material, then 50mm is a typical minimum thickness. There's a 'rule of thumb' that we use with fill layers - they should always be at least twice the thickness of the largest particle size. This is done to ensure that no 'points' are created within a layer, that is, no particle or lump of stone can be in contact with both upper and lower surfaces at any time, but by definition must be 'cushioned' by finer material either above, below, or both above and below. This ensures that the layer acts to spread the loads it carries, but also ensures there are no 'rocking points' within the layer.

Can my parents live in a caravan in my garden?

The answer is yes, but you can't use the caravan as accommodation. It must be used in association with the use of the land. On farm land the...

Last updated Aug 5, 2020

What is cheaper cement or concrete?

Is cement cheaper than concrete? Cement is not usually cheaper than concrete. This is because cement is the main ingredient of concrete. Once...

Last updated Jun 8, 2020

Can I build my own shed?

Yes, with the right plans you can build your dream shed.

Learn More »

Promotion

So, if maximum particle size is "x", then minimum layer thickness is "2x", as shown opposite. DTp1 has, in theory, a maximum particle size of 37½mm, so using this 'rule of thumb', the min layer thickness would be 3½ × 2 = 75mm. If a fill layer or sub-base layer was using a 50mm crusher run material, then the minimum layer thickness/depth would be 50 × 2 = 100mm, and so on and so forth. Conversely, if we know that we have space for only 50mm of fill material, then the maximum particle size would be 50 ÷ 2 = 25mm. So, assuming a sub-base is going to be used, just how deep should it be? This is revealed in Table 2 below.

Project Typical depth

Patios, Garden Paths 75-100mm

Driveways, public footpaths 100-150mm

Heavy uses 150-225mm

Highways 150mm +

Table 2: recommended sub-base depths using DTp1

Can I use old housebricks as a sub-base?

Sub-bases aren't included in a pavement just for fun - they are often the key load-bearing layer, and trying to save a few bob by using old house bricks or other rubbish you have lying around is often a false economy. How would you feel if a carpet fitter suggested using a few old tea towels under your living room carpet, instead of proper underlay, as it would save a bit on cost??

The trouble with using old bricks is that folk tend to chuck them in 'as is', whole bricks and half-bricks dumped haphazardly over the sub-grade, with hundreds of gaps and voids between them. The same goes for other so-called 'hardcore' such as old flagstones, edging kerbs, broken lumps of concrete and the like. After a few weeks, any finer material used as additional fill, and/or the bedding material, starts to trickle down and settle into all those voids. And that's not an end to it - following this initial settlement, the outline of the bricks starts to show through, and so you find that, for instance, bitmac follows the ups and downs of the bricks, and flags start to 'rock' on the high points. Here’s a picture of what is meant about folk using full bricks as a sub-base…. …it’s a big NO-NO!! Even breaking them in half isn’t ideal. Although this does tend to reduce the problems, it doesn’t get rid of them altogether. What you need to do is break up the bricks into quarters or smaller – the smaller the better – and then ‘blind’ them with grit sand, rock fines or crushed stone, so that all the voids between the smashed bricks are filled, and then compact the lot, repeatedly running the vib plate or roller over the area until all the ‘fines’ are rattled into the voids and you have a reasonable ‘capping layer’.

What is a Barndominium house?

A barndominium, also known as a barndo, is an open concept steel building with large square footage that combines living space and a working area....

Last updated Sep 7, 2020

What is the best way to stack firewood?

Stack wood in a single row, out of the shade, with enough space between the pieces to allow air to pass through. This exposes more wood to sunlight...

Last updated Sep 2, 2022

Can I build my own shed?

Yes, with the right plans you can build your dream shed.

Learn More »

Promotion

You can then regulate the top of this layer with 75mm or more of quality sub-base material – a DTp1, DTp2, or a crusher-run material. Skimping on the sub-base is one of the surest ways of shortening the life of any driveway. For what it costs, spending a few quid extra on quality sub-base material is a sound investment that will pay for itself over the years of extended service it enables.
