Does a vent stack have to go straight up?

Vent pipes must be installed so they stay dry. This means that they should emerge from the top of the drainpipe, either straight vertically or at no less than a 45-degree angle from horizontal, so that water cannot back up into them.

bhg.com - Everything You Need to Know About Venting for Plumbing Work

Does a shed increase property tax in Ohio?

They may not add substantial value to your home financially, but that also means they do not affect property taxes (at least in most instances)....

Last updated Apr 22, 2020

How thick does a shed floor need to be?

The best concrete thickness for a shed tends to be 4 inches which is the standard size used for most residential concrete patios, walkways and...

Last updated Sep 4, 2018

Promotion

Drain-waste-vent (DWV) pipes carry waste and water smoothly out of the house without gurgles or fumes. This requires an air passageway behind the water. Vent pipes extend from the drainpipes up through the roof to provide that passage while also carrying odors out of the house. Figuring out how the drain will be vented is one of the first steps as you plan for plumbing a new appliance or an addition to your system. However, it's not always an easy solution to find. When developing a plumbing system plan, you can choose from several venting types, and each option could present problems or complications. Get the details on each type of drain vent below to assist you in planning your remodel. Before finalizing a plan, make sure to have the venting scheme approved by a local plumbing inspector.

Dustin Peck

Why Is Venting Necessary?

Try to quickly empty a bottle with a narrow mouth; it will gurgle and glug as it slowly empties. Open the vent cap on a plastic gas container and it flows smoothly. That's because the vent hole allows air to enter behind the flowing liquid, producing a quick, glug-free flow. Vent stacks in a household plumbing system work the same way. The centerpiece of a DWV system is the main stack, usually a pipe 3 or 4 inches in diameter that runs straight up through the roof. A secondary stack, perhaps 2 or 3 inches in diameter, serves a branch of the system. Branch drainpipes of smaller diameter (typically 1½ or 2 inches) carry water from specific fixtures to a stack.

Vent Types to Know

A true vent is a vertical pipe attached to a drain line that travels through the roof with no water running through it. If a fixture is close to the stack and on the top floor, the upper part of the stack serves nicely as a vent. Many fixtures are not so conveniently located, however, and other solutions must be found. A revent pipe, also called an auxiliary vent, attaches to the drain line near the fixture and runs up and over to the main vent. It can attach directly behind the fixture or to the horizontal drain line. If two fixtures are on opposite sides of a wall, they can tie into the stack with a sanitary cross. This is called a common vent and can be found on back-to-back sinks. When a fixture is close enough to a stack, a wet vent might be allowed by code. In the case of a tub that is close to a stack, its drain can empty into a pipe that also serves as a vent.

How big is a 2 car garage?

How Many Square Feet is In a 2 Car Garage? The average sized 2 car garage's square footage usually ranges from 400 (20×20), 576(24×24), and 720...

Last updated Oct 7, 2019

What is the weakest point of a door?

What are the 3 weakest points of a door? A door is usually most vulnerable at its strike plate, its hinges, and its existing lock hardware....

Last updated Jul 6, 2019

Promotion

For a freestanding sink, code might allow a loop vent. If reventing is difficult and wet venting isn't allowed, you might have to install a separate vent pipe through the roof. An air admittance valve (AAV) opens to let air in when waste drains, then gravity closes it to keep sewer gases from escaping back into the room. Codes in many localities allow these relatively new devices to take the place of vent lines. Depending on the size of the unit and any code restrictions, AAVs can be used to vent multiple fixtures. Check codes to make sure they permit AAVs.

How Far Should a Fixture Be From a Vent Pipe?

When you're remodeling your plumbing system, can you install a wet vent, or do you have to install a revent or a separate vent? Finding the answer can involve complicated calculations, based on formulas that can vary from one locale to another. The critical distance, or how far the fixture can be from the vent pipe, is determined by three factors: the size of the pipe that codes require, the type of fixture you want to install, and the number of fixtures that are already wet vented on the same line. Measure the length of the pipes carefully and consult a plumbing inspector to determine whether wet venting is possible.

BHG / Michela Buttignol

Tips for Installing Vent Pipes

Vent pipes, often narrower than drainpipes, need not slope like drainpipes. Normally they run level or plumb unless there is an obstacle to work around. Vent pipes must be installed so they stay dry. This means that they should emerge from the top of the drainpipe, either straight vertically or at no less than a 45-degree angle from horizontal, so that water cannot back up into them. The horizontal portion of a revent pipe must be at least 6 inches above the fixture's flood level, or the highest point to which water can rise. On a sink, for example, the flood level is the sink rim or overflow hole.

What to Know About the Main Drain

Do you insulate the roof of a shed?

Roof insulation Insulating a shed roof is typically done using insulation below the roof deck and between the rafters. Care is needed to ensure...

Last updated Jun 23, 2021

Why do you not put wood in concrete?

With concrete holding the moisture against the wood, wood has no chance and will eventually lose the battle. Now you don't have to lose all hope...

Last updated Jan 27, 2021

Can I build my own shed?

Yes, with the right plans you can build your dream shed.

Learn More »

Promotion

Plan drain lines to minimize the possibility of clogs. The general rule is that smaller drainpipes (1¼ inches for bathroom sinks and 1½ inches for kitchen sinks, for instance) lead to larger branch drains. These in turn lead to the main stack, which is the largest pipe of all (typically 4 inches). Because the main stack is also vertical, it will rarely clog. Water travels downward through the stacks to the main drain line, an underground horizontal pipe that leads to the municipal sewage system or to a septic system. In older homes, the main drain might be made of clay pipe or other porous material. Tree roots sometimes work their way into the main line, causing wastewater to back up into the house. The solution is to call a company that specializes in augering main lines.

Dave Toht

Typical Venting Alternatives

A true vent pipe must remain dry while water runs down the drain. A wet vent also serves as a drain line but is large enough that it never actually fills with water. In some cases, local codes allow for other venting strategies. For instance, a basement sink might be vented with a special wall vent, which simply runs out the wall. Alternatively, a cheater vent, a small device that draws air from the room rather than outside, might be allowed.

Illustration by Dave Brandon

Window framing in this wall prevents the installation of a vent line, so an air admittance valve (AAV) is installed instead. As the fixture drains, the one-way valve opens to balance the negative pressure and draw air back into the pipe before closing again. This helps prevent slow draining, gurgling, or the release of sewer gases into the home.

Dave Toht

Other Venting Options

Other common ways to tie vents into a stack include sanitary crosses, revent alternatives, and loop vents installed at least 6 inches above flood level. Check local codes to see which methods are accepted in your area, then choose the method that requires the least number of holes or notches in studs.
