Get the complete 8×10 Garden Shed plans – PDF Instant Download:

8×10 Garden Shed Plans | Free DIY Woodworking Guide

Material and Cut List

FLOOR

9 – 2×6 Pressure Treated Lumber: 7′-9″

2 – 2×6 Pressure Treated Lumber: 10′

4 – 4×4 Pressure Treated Lumber: 10′

3 – 23/32″ Tongue and Groove Plywood 4′ x 8′ Sheet (cut to size)

WALLS

41 – 2×4 Lumber: 7′-4 1/2″

2 – 2×4 Lumber: 9′-5 ”

4 – 2×4 Lumber: 10′

2 – 2×4 Lumber: 8′-0″

4 – 2×4 Lumber: 7′-5″

SIDINGS

10 – 4′ x 8′ Plywood Siding Panel T1-11 (315SF)

TRUSS

10 – 2×4 Lumber: 6′-6 1/4″

5 – 2×4 Lumber: 10′

5 – 2×4 Lumber: 2′-2 1/2″

4 – 2×4 Lumber: 2′-6 3/8″

Metal Gusset (reference detail for sizing)

PURLIN & ROOF

10 – 2×4 Lumber: 9′-8″

4 – 4′ x 8′ 1/2″ Plywood Sheet (132SF)

Roof Underlayment (132SF)

3-Tab Roof Shingles (132SF)

ROOF TRIM

4 – 1×6 Lumber: 6′-8 1/8″

2 – 1×6 Lumber: 9′-8″

4 – 1/2″ Plywood: 10 3/8″ x 6-5 3/8″

2 – 1/2″ Plywood: 8′- 3/4″

TRIM

8 – 1×4 Lumber: 7′-9 5/8″

HARDWARE

3 1/2″ Galvanized Steel Nails

2″ Deck Screws

2″ Galvanized Finishing Nails

1 1/2″ Drilling Roofing Screws

DOUBLE DOOR FRAME

2 – 2×4 Lumber: 6′-3 1/2″

6 – 2×4 Lumber: 7 1/2″

2 – 2×6 Lumber: 6′-3″ (door header)

1 – 2×6 Plywood Filler: 6′-3″ (door header)

1 – 2×6 Lumber: 6′-7″ (door trim)

2 – 2×4 Lumber: 6′-5″ (door trim)

WINDOW (optional)

4 – 2×4 Lumber: 7′-4 1/2″

2 – 2×6 Lumber: 3′-2 3/8″ (header)

2 – 2×4 Lumber: 3′-2 3/8″

2 – 2×6 Lumber: 3′-6 3/8″ (window trim)

2 – 2×4 Lumber: 2′-11 1/4″ (window trim)

1 – 35 3/8″ x 35 3/8″ Single Hung Vinyl Window

Step 1 – Foundation and Floor

Start with selecting a proper site for the shed foundation, ideally a flat solid surface away from any large trees. The first step is cut nine 2×6 lumbers to 7′-9″ length, and two 2×6 lumbers to 10′-0″. Next, place the four 10′ 4×4 lumbers parallel to each other spaced evenly apart. Then, assemble the four 2×6 perimeter frame on top, this will outline the overall floor frame. Drill pilot holes through the joists and secure with 3 1/2″ screws. Finally, install the seven 2×6 floor joists at 16″ O.C., and 12″ O.C. near the sides. After the floor frame is secured, cut the tongue and groove 23/32″ plywood to size and attach to the frame. You’ll need about 4 full sheets to cover the 80SF floor area. These sheets usually come in standard sizes of 48″ x 96″. Insert 2″ deck screws every 8″ along the joint, don’t leave any gaps between the sheets. Refer to the cut pattern and dimensions illustrated below:

Step 2 – Walls

Start with the front wall frame first, all frames used here are 2×4’s (except the door and window header which are 2×6’s). Cut two 2×4 to 10′ in length, these will be used for the top and bottom plates. Then, cut eight 2×4 to 7′-4 1/2″ for wall studs, these will be placed 16″ O.C. You’ll also need to cut out a 9′-5″ 2×4 for the double top plate. Drill pilot holes through the plates and insert the 3 1/2″ screws into the studs to secure in place. Align the frame edges and make sure all corners are flush for a professional result.

Why are wood pallets painted blue?

Of course, this means CHEP has to keep track of all those pallets, which is not easy. David Lee says it's why all the pallets are painted blue - so...

Last updated Jul 17, 2019

What kind of gravel is best?

5 Types of The Best Surface Gravel for Driveaway Crushed Stone #411. It is crushed up #57 stone combined with rock dust. ... Quarry Process. It is...

Last updated Sep 7, 2022

Promotion

See detailed Door and Window framing instructions here:

The 2 x 4 studs holding up the door header need to be cut at 6′-3 1/2″. To construct the door header, cut two 2×6 lumber to 6′-3″ length, and insert 1/2″ plywood as filler. Use wood glue and 3 1/2″ nails to secure all the pieces together. Align the finished front wall frame with the front edge of the floor foundation: Next up is the building the shed’s back wall. Cut two 2×4’s to 10′ length, and 11 more 2×4’s to 7′-4 1/2″ length. Then cut out a 9′-5″ 2×4 as the double top plate. Follow the framing plan below. Space the wall studs to 16″ O.C., identical to the front wall. Drill pilot holes through the plate and insert 3 1/2″ screws to secure the studs. Continue the build by assembling the 2 side wall frames. Cut two 2 x 4’s lumber to 7′-5″ as top and bottom plate, then a full 8′ 2×4 as the double top plate. then cut ten 2×4’s to 7′-4 1/2″ for the wall studs. Now it’s time to secure all four wall frames together. First, line up the edges of the front and side wall frame with the floor frame perimeter. Make sure edges line up and there’s no gaps, use a spirit level if needed. Then, drill pilot holes through the bottom wall plate, and insert 3 1/2″ screws to secure wall frame to the floor. After both wall frames are secured, lock the adjacent walls together by inserting 3 1/2″ screws or nails.

Repeat and assemble all 4 wall frames.

Step 3 – Roof & Truss

The roof will require a total of 5 identical kingpost style trusses, installed 24″ O.C. There are also two cross bracing placed on both ends for added stability. The trusses are designed to have an overhang of 10″ on both sides.

Refer to the truss details below for dimensions and assembly instructions.

Tip: make 1 truss first and make sure everything fits in place.

After you’ve finished assembling the trusses, place them 24″ O.C. on top of the wall frames. Then use 3 1/2″ nails to secure each rafter from the underside of the plate. Attach the two set of cross bracing at midpoint of the end truss bays. The next step is to add purlins on top of the trusses. Measure and cut out 10 2×4 lumbers to approximately 9′-8″ in length. Center the purlins to leave about 10″ of overhang, secure to the trusses with 3 1/2″ nails. After all the purlins are secured in place, measure and cut the 1/2″ plywood panels to size. These sheets usually come in standard 96″ x 48″ size, you’ll need about 132SF to cover the entire roof area. Insert 2 1/2″ nails into the purlins at about every 10″ to lock the plywood sheets in place.

Is it hard to get approved for a second home?

Because a second mortgage generally adds more financial pressure for a homebuyer, lenders typically look for a slightly higher credit score on a...

Last updated Jun 19, 2022

How can I make an extra $2000 a month?

Whatever your ultimate goal, there are several ways you can easily work from home to earn thousands more each month. Freelance Writing. ... Become...

Last updated Oct 7, 2018

Promotion

Measure and cut 10 T1-11 plywood siding panels to size. These shed panels are designed to interlock, so plan them out accordingly. These siding panels also come in standard sizes of 96″ x 48″, you’ll need about 315SF to cover the entire shed. For the front wall siding, measure and cut out the door and window openings before installing. The rough door opening is 72″ x 77″, and the optional window opening is 2′-11 1/4″ x 2′-11 3/8″. Cover the entire roofing area with roof underlayment or tar paper, this is a water-resistant barrier material to keep the wood structures dry. An 8×10 size shed will need about 132SF to cover the entire roof. Finally, we need to lay out the roof shingles (132SF of 3-tab roof shingles). Start at the bottom of the roof, measure and mark every increment height all the way to top of the roof. Use glue or glue strip along the rake edge and drip edge. Then, insert 2 1/2″ nails to secure in place. Tip: You can select the roof shingle material to match the roofing material of the main house, for a unified look! Get samples from your local hardware or home renovation store to get a close match.

Step 4 – Trims, Door, and Window

For the wall trims, measure and cut eight 1×4 lumbers to 7′-9 3/4″, trim the top angle as needed. Align and secure these trims with 2 1/2″ nails into the wall frames. As for the door trim: use a 6′-7″ long 2×6 as the header trim, and two 6′-5″ long 2×4’s as frame trims. The window will require a 42 3/8″ 2×6 header, and 35 1/4″ side trims. Secure all trims to the studs with 2 1/2″ nails.

Step 5 – Paint

Your 8×10 Garden style shed is complete! Now it’s time to style it up a little. First, wipe off any dirt or dusts off the T1-11 siding surface and the trims. Prime the siding with a heavy acrylic primer, a single thorough coat will do the job. It’s best to use a small brush to fill in the grooves and corners first, and then use a larger roller to cover up the flat areas. Let it sit and dry. Then apply two coats of exterior grade acrylic paint, allow 2 hours between coats to completely dry.
