Which is better AFCI or GFCI?

GFCI Receptacles are more preferred than its breaker. The AFCI breakers are more preferred than its receptacles. The GFCI usually prevents electrocution from the connected load. The AFCI usually protects from arcs in branching circuits.

electricaltechnology.org - What is the Main Differences Between GFCI and AFCI?
Does B&Q sell off cuts of wood?
Does B&Q sell off cuts of wood?

If you're not that handy with a saw or don't have the space at home, most of the stores offer a timber cutting service. They'll cut the wood down...

Read More »
Last updated May 14, 2022
Can snakes slide under doors?
Can snakes slide under doors?

Can Snakes Crawl Under Doors? The space under doors in most conventional homes is too tiny for snakes to crawl under. However, any cracks or gaps...

Read More »
Last updated Feb 1, 2018

Differences between GFCI & AFCI – Ground Fault vs Arc Fault Circuit Interrupter Faults generated in electrical wires can cause serious injuries to any person & damages to the property if they are left unattended. These faults happen so quickly & can cause accidents that could end up fatal in a matter or milliseconds. In order to prevent such accidents, we use various kinds of protection devices where GFCI (Ground Fault Circuit Interrupter) & AFCI (Arc Fault Circuit Interrupter) are two of these devices used for protection against ground fault & arc fault respectively. Both of these devices break the circuit in case of such fault & there are various differences between them. Before going into the list of differences between GFCI and AFCI, we are going to discuss about ground fault, arc fault & the basics of these two devices.

Ground Fault

The Ground fault means when the current flows in the unintended path. In a normal situation, the current should flow from the hot wire into the neutral wire. If the current leaks out of the circuit through a ground wire or any person’s body that came into contact with the ground is said to be a ground fault. The ground fault occurs when the phase wire completes the circuit with the ground. That’s why a proper earthing and grounding is needed in each and every electrical isntallations systems.

Arc Fault

An arc fault is a discharge of a very high power between two or more than two conductors. The arc is generated due to loose cable joints or damage in a flexible cable due to twisting or exposure to heat. Continuous arc generates heat energy that could result in an electrical fire. The arc varies in power & capacity. Normal arcs that are generated every time you toggle a switch or plug a device are not considered as arc faults because they do not cause damage.

GFCI (Ground Fault Circuit Interrupter)

GFCI is an abbreviation for Ground Fault Circuit Interrupter, it is a protection device that offers protection against ground fault or leakage current. It pops off & breaks the supply when it senses any leakage current flowing out from the circuit. This leakage current caused by the ground fault flows through a human body & wet appliances. Therefore, GFCI helps in prevention against electrical shock & that is why they are installed in wet locations such as bathrooms, kitchen, outdoor etc. It continuously monitors the current going into the load (appliance) “through hot or live wire” & flowing out of the load “through Neutral Wire”. If there is any difference between the two, the GFCI breaks the current supply. The difference occurs due to the leakage current flowing through the grounded body of a person when the appliance comes into contact with water.

Is thicker concrete less likely to crack?
Is thicker concrete less likely to crack?

Concrete of a thickness of less than 5″ is more prone to cracking, unfortunately this includes nearly all the poured slabs out there. Slabs 4″...

Read More »
Last updated Aug 14, 2022
What are the types of workshop?
What are the types of workshop?

5 Types of Workshops and How You Can Use Them in Your Classroom Invitational Workshop. An invitational workshop is what many of us know. ......

Read More »
Last updated Apr 16, 2018

The GFCI uses logic circuitry to sense the current flowing into & out of the appliance. The live wire & neutral wire both run through a CT (current transformer), that will generate no output under normal condition (equal current in live & neutral wire cancels each other effect). If there is an imbalance between them, the CT will generate some output & the logic circuitry detects it. If the current exceeds a certain limit, the logic circuitry breaks the circuit. It is a very sensitive device that can sense very low current differences. It breaks the circuit when the leakage current exceeds 5 mA within 25ms. The current limit & the tripping time are crucial to protect any person from electrical shock. Because a minimum of 10mA of current through a person’s body is fatal if exposed for a prolonged period of duration. It has “Test Button” & “Reset Button” usually in black & red colors respectively. It is the main indication of any outlet that has GFCI protection. The “test button” is used for verification of its operation. It momentarily connects the live wire with the neutral wire with in the outlet. The “Reset button” is used for resetting the power supply after it breaks. But you should not press it before disconnecting the appliances connected with it. The GFCI will never trip due to overloading or any short circuit in the appliance connected. But it will trip the circuit breaker connected with the said GFCI outlet.

AFCI (Arc Fault Circuit Interrupter)

AFCI stands for Arc Fault Circuit interrupter; it is a protection device that offers protection against Arc faults. The arc faults are high power discharges between two conductors. The continuous arc can generate enough heat to start a fire & could cause serious damage to property & life. The AFCI breaks the circuit upon sensing any arc in the circuit. The arcs are generated due to incorrect or loose joints in cables or damaged cables by nail, twisting, kinking, etc. Any loose connection in a power point or old cables may also cause an electrical arc. These continuous arcs can generate enough heat to start a fire & it can disrupt the operation of any sensitive electronic device. The arcs generate a non-periodic waveform that is detected by using a sensitive logic circuit. It discriminates between a normal arc & an arc fault. As soon as the arc is detected the circuitry trips the power supply but it cannot prevent the first arc. Although it can prevent the ones that follow & avoid a potential fire hazard.

Can you pour concrete directly over dirt?
Can you pour concrete directly over dirt?

Long story short, yes you can pour concrete over dirt. Jul 1, 2020

Read More »
Last updated Feb 28, 2022
How long should logs sit before splitting?
How long should logs sit before splitting?

six months Let the wood dry at least six months and preferably longer The hardest lesson: firewood takes a very long time to season Most folks who...

Read More »
Last updated May 4, 2021

The AFCI has a “Test & Reset button” that is used for verifying its operation & resetting the power supply after it trips. The test button feeds an arc-like waveform to the arc detector in its logic circuit. If the AFCI is switched on, pressing the test button will trip the circuit if it works properly, otherwise, it is defected & you should ask for a professional to inspect it.

Main Differences between GFCI and AFCI

GFCI AFCI it is a protection device that offers protection against Ground faults. It is a protection device that offers protection against Arc fault. It stands for Ground Fault Circuit Interrupter. It stands for Arc Fault Circuit Interrupter. It breaks the circuit when there is a leakage current. It breaks the circuit only when there is an electrical arc in the circuit. electrical shocks. It helps in the prevention of It helps in the prevention of electrical fire caused by an electrical arc. It must be installed in only wet areas such as bathrooms, pools, kitchen etc. It is required to be installed in a branching circuit that provides power to outlets in the residential room, dining room, etc. GFCI Receptacles are more preferred than its breaker. The AFCI breakers are more preferred than its receptacles. The GFCI usually prevents electrocution from the connected load. The AFCI usually protects from arcs in branching circuits. It protects from accidents that happen outside the walls. It prevents accidents from happening inside the walls. GFCI is often installed at the power outlets in wet areas. The AFCI breakers are installed at the main electrical panel. The conclusion of this article is that the GFCI is used for prevention of electrical shocks & the AFCI is used for the prevention of electrical fires.
